Scag Patriot

Contact us for price

The Scag® Patriot™ zero-turn riding lawn mowers with heavy-duty design and aluminum, sealed ball bearing, blade-drive spindles provide reliable performance.

Call Us Now

Specs

ModelDescriptionMSRP
SPZ-52H-23CV52" Hero Cutter Deck, 23 HP $8,948
SPZ-52H-27CX52" Hero Cutter Deck, 27 HP Briggs CXi Series™ – V-Twin $8,948
SPZ-52H-22FX52" Hero Cutter Deck, 22 HP FX691 $9,031
SPZ-61H-25CV61" Hero Cutter Deck, 25 HP $9,514
SPZ-61H-27CX61" Hero Cutter Deck, 27 HP Briggs CXi Series™ – V-Twin $9,514
SPZ-61H-23FX61" Hero Cutter Deck, 23 HP FX730 $9,821
* Limited availability. Contact your local Scag dealer for specific availability information.
SpecificationPatriot
GeneralTotal Fuel Capacity6.5 gallons
Drive Tires22" x 10.5"-12" (52")

24" x 12"-12" (61")
Caster Tires13" x 6.5"-6"
SeatTorsion-spring suspension seat
Drive SystemDrive System TypeHydro-Gear ZT3100 Transaxle (52")

Hydro-Gear ZT3400 Transaxle (61")
PumpsZT3100 Internal Pump: 10 cc (52")

ZT3400 Internal Pump: 12 cc (61")
MotorsInternal Motor: 16 cc
Forward Ground Speed8.5 mph (52")

10 mph (61")
Reverse Ground Speed5 mph
Parking BrakeFoot-operated pedal
DeckCutting Widths52" and 61"
TypeHero Cutter Deck
Cutting Height1.5" to 5" in .25" increments
Deck LiftFoot-operated pedal
ConstructionDual-plate cutter deck constructed of 2 steel plates. Reinforcement plate at cutter deck spindles.
SpindlesAluminum housing with sealed ball bearings.
Blade EngagementOgura GT2 (108 ft lb)

Adjustable air-gap for extended life.
